C6 single pole miniature circuit breaker (MCB) is a micro electrical safety switch for protecting electrical circuits from overloads and short circuits. This mini circuit breaker handles 6A current and is commonly used in residential, commercial, and industrial applications.

Single Pole MCB Breaker Information

• Rated Current: 6 amp
• Rated Voltage: 230/400V AC, 50Hz
• Number of poles: 1 pole
• 6 kA rated short-circuit breaking capacity
• Compliant with IEC standard
• C curve trip characteristic
• With overload protection and short circuit protection function

Technical Data

Single Pole MCB Breaker Dimension (Unit: mm)

Details

Tips: The ultimate short-circuit breaking capacity and operating short-circuit breaking capacity of miniature circuit breakers

• Ultimate short-circuit breaking capacity (I_cu): According to the conditions specified in the prescribed test procedures, excluding the breaking capacity of the circuit breaker to continue to carry its rated current capacity, in plain language, it means that this circuit breaker has a short-circuit fault when in use The expected maximum short-circuit current can be interrupted at a time without causing damage to the line, and the line is protected, but the micro-break is damaged or burned out and can no longer be used.
• Operating short-circuit breaking capacity (I_cs): According to the conditions specified in the prescribed test procedures, including the breaking capacity of the circuit breaker to continue to carry its rated current capacity, in plain language, it means that when the circuit breaker is in use, the line has a short circuit fault It can break not more than a certain proportion of the expected maximum short-circuit current at a time without causing damage to the line. The line is protected, and the circuit breaker it self can still be used without damage.
