48V 1500W Switching Power Supply

0 reviews • Write a review

from

$205.66

Ex Tax: $205.66

Stock: In Stock
Model: RDDLZ-SMPS-1500-48
Weight: 1.00
SKU: RDDLZ-SMPS-1500-48

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Low price and high efficiency 48V switch mode power supply convert AC input to DC output at a rated current of 31.2A. This 1500W SMPS switched mode power supply comes with overvoltage and over-temperature protection, strong anti-interference ability, efficient work and good performance, perfect for all kinds of electrical equipment or devices.

Specifications

Model	RDDLZ-S-1500-48
Output	DC Voltage	0~48V
	Rated Current	31.2A
	Rated Power	1500W
	Ripple and Noise ①	≤2400mV
	Voltage Accuracy	±1%
	Output Voltage Adjustment Range	±10%
	Load Regulation	＜±0.5
	Linear Adjustment Rate	＜±1%
Input	Voltage Range	180~264V AC 47Hz~63Hz; 254V DC~370V DC
	Efficiency (Typical) ②	＞85%
	Working Current	220V AC, 13.5A
	Electric Shock	60A 230V AC
	Start, Rise, Hold Time	800ms, 50ms, 20ms; 230V AC
Protection	Overload Protection	105%~135% Type: constant current output +VO drops to the undervoltage point and cuts off the output; Reset: power on again
Protection	Over Temperature Protection	RTH3: The fan rotates continuously, and the output is turned off when >90℃.
Environment	Temperature & Humidity	-10C~+50℃; 20%~90RH
Environment	Storage Humidity	-20C~+85℃; 10%~95RH
Safety & EMC	Withstand Voltage	Input-Output: 1.5kV AC; Input-Enclosure: 1.5kV AC; Output-Enclosure: 0.5kV AC
	Leakage Current	Input-Output: <6mA at 1.5kV AC
	Leakage Current	Input-Output: <1.5mA at 220V AC
	Isolation Resistor	Input-Output, Input-Enclosure, Output Enclosure: 500V DC/100MΩ
Size	292x133x70mm
Net Weight	2.7kg

Features

High-quality capacitors: 48V switching power supply uses high-quality electrolytic capacitors, which have large capacity, low loss, and are more durable and safer.
Pure copper transformer: It is equipped with sufficient turns of coil winding, with reliable performance, full power and stable operation.
EML filter: RDDLZ 1500W switch mode power supply has strong anti-interference ability, efficient work and good performance.

Details

Dimension (Unit: mm)

SMPS Power Supply Applications

Power Tools: Electric Saw, Drilling Machine, Ginder, Sand Blast Machine, Punching Machine, Weeding Machine, Air Compressor, etc.
Office Devices: Computer, Printer, LCD Monitor, Scanning Machine, etc.
Electrics & Household Appliance: TV, VCRS, Radio, Dust Collector, Fan Lamp or LED Strip, Sewing Machine, Microwave Oven, Fridge/Freezer, Coffemarker, etc.
Industrial Equipment: Monitoring Equipment, Shipping, Vehicle, Metal halide Lamp, Solar System, Wind Power Generation, etc.

Tips: How to select the right switching power supply for my application?

Selecting the right switching power supply for your application involves considering several key factors. First, determine the required output voltage and current specifications. Ensure the power supply can deliver the necessary power. Consider the input voltage range and ensure compatibility with your power source. Efficiency and size are crucial, so choose a model that offers high efficiency and fits within your space constraints. Look for additional features such as protection mechanisms and certifications to meet safety and regulatory requirements. Finally, assess the reliability and reputation of the manufacturer. A thorough evaluation of these factors will help you select the most suitable switching power supply for your specific application.
