4000W Marine Power Inverter

4000W Marine Power Inverter
4000W Marine Power Inverter
4000W Marine Power Inverter
4000W Marine Power Inverter
4000W Marine Power Inverter
4000W Marine Power Inverter
4000W Marine Power Inverter
from
$4,533.08
Ex Tax: $4,533.08
  • Stock: In Stock
  • Model: RDDLZ-MPI-4KW
  • Weight: 1.00
  • SKU: RDDLZ-MPI-4KW

Available Options

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Buy a 4000W power inverter for boat,  available with 120V input DC voltage, 33V input DC current, 110/120/220/230/240V output AC voltage, 50Hz or 60Hz frequency, and communication interface RS485. This marine inverter can convert the battery (DC power) on board into AC power for common electrical equipment on board.

Features

  • 4000 watt marine inverter utilizes the U.S. DSP28335 control chip for fast running speed and high precision, with a conversion efficiency of over 92% and a built-in industrial frequency isolation transformer for strong anti-interference and impact resistance.
  • The boat inverter is equipped with over-voltage, over-current, short-circuit, and overheating warning devices, along with frequency conversion starting and reduced voltage soft start functions, suitable for high-power motor startups.
  • Good price marine power inverter features an LCD and LED alarm indicators for easy operation, provides a pure output waveform with less than 3% distortion, and supports single-phase power supply with output voltage range of 110/120/220/230/240V AC.

Specifications

ModelRDDLZ-SDP-4KW
Isolation ModeLow-Frequency Transformer
DC InputVoltage Range (V DC)120V (Contact Us for Other Voltage)
Rated Current(A)33A (Contact Us for Other Current)
AC OutputRated Output Power4kW (4000 watt)
Output WaveformPure Sine Wave
Rated Voltage110/120/220/230/240V AC (Optional)
PhasesSingle Phase
Rated Current (A)18A
Frequency50Hz or 60Hz
Rated Output Voltage Range (V)110/120/220/230/240V AC (Optional)
Power Factor (PF)0.99
Overload Ability150%, 5 seconds
Efficiency>93%
Waveform Distortion Rate (THD)<3% (Linear load)
Dynamic Response (0 to 100% Load)5%≤50ms
DisplayLCD
Running ModeWorking Continuously
Electrical Insulation Properties2000V AC, 1min
Communication InterfaceRS485 (Optional)
Protection FunctionProtectionInput Reverse Polarity, Under Voltage, Overvoltage, Output Over current, Shortcircuit, Overheating, etc.
Cooling MethodFan-cooled
Short-circuit ProtectorNo Automatic Recovery Need to Restart the Machine
Working
Environment
Noise (1m)≤50dB
Degree Of ProtectionIP20 (Indoor)
Working Altitude (m)≤2000
Working Temperature-25~+55℃
Relative Humidity0~90% (Non-Condensing)
Rack Mounted TypeDepth*Width* Height435*605*267mm
Stand Type450*550*760mm


Applications

Tips: What can a marine inverter do?

The marine inverter is a crucial device in marine applications that converts direct current (DC) from a boat’s battery system into alternating current (AC), which is used to power standard household appliances and electronics. This conversion is essential for boats that need to run devices like microwaves, refrigerators, televisions, and other AC-powered equipment when not connected to shore power. The inverter ensures a smooth and reliable power supply, enabling the use of these appliances during long voyages or while anchored away from docks with electrical hookups.

Beyond powering household appliances, marine inverters also play a critical role in enhancing the overall functionality and comfort of marine vessels. They often come equipped with additional features such as battery charging capabilities, surge protection, and remote control operation. High-quality inverters can manage power more efficiently, reducing energy waste and extending battery life, which is vital for long-term sustainability on the water. By providing consistent and reliable AC power, marine inverters contribute significantly to the safety, convenience, and enjoyment of life on board.
