3/8 Inch Stainless Steel Needle Valve, DN10

0 reviews • Write a review

from

$61.66

Ex Tax: $61.66

Stock: In Stock
Model: RDDLZ-NV-DN10
Weight: 1.00
SKU: RDDLZ-NV-DN10

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This needle valve cannot be used for drinking water.

Buy an RDDLZ stainless needle valve online, the pin valve with 3/8 inch thread, a diameter of 5mm, connection thread size of DN10, max. pressure is 6000 psi and the working temperature is -20 to 180 °C. The shut-off valve's thread guarantees the stable performance of the connecting, good sealing and no leakage.

Specification

Model: RDDLZ-NV-DN10
Size: 3/8 inch
Connection thread size: DN10
Needle valve diameter: 5mm
Nominal pressure: 40 MPa
Material: 304 Stainless Steel
Working pressure: ≤420 bar
Working temperature: -20~180℃
Installation method: Screw connection
Medium: Gas, liquid

Features

Smooth and accurate flow control
With a very compact design and reliable leak tight shut off
High pressures up to 6000 psi
Wide temperature range from -20 up to 180°C.
Suited for aggressive fluids thanks to the 304 stainless steel

Dimension

Model	A	B	C	D
RDDLZ-NV-DN10	57mm	92mm	27mm	5mm

Stainless Steel Needle Valve Application

Tips: What is the difference between a globe valve and a needle valve?

What is the difference between a globe valve and a needle valve? A needle valve is a special kind of globe valve in which the plug is needle-shaped rather than disc shaped. A needle valve is able to provide a very fine level of flow control which is useful for precision equipment.
