2kW Vertical Hydroelectric Turbine Generator, Axial Flow

0 reviews • Write a review

from

$1,615.71

Ex Tax: $1,615.71

Stock: In Stock
Model: RDDLZ-HT-2KW
Weight: 1.00
SKU: RDDLZ-HT-2KW

Available Options

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Note: This 3kW vertical hydroelectric turbine generator cannot be used for drinking water.

Portable 2000 Watt vertical hydro generator utilizes an axial flow design, requires only 4-7m head and 0.09-0.11m³/s flow, delivers 220V output, features a removable design for easy maintenance, ideal small water turbine for low-flow water sources.

Specification

Power	2kW
Voltage	220V
Applicable water head	5m ~ 30+m
Volume of water flow	0.0114 ~ 0.0230 m³/s
Design Head	1.5m ~ 3m
Design Flow Rate	0.03 ~ 0.04 m³/s
Waterleaf Diameter	18cm
Speed	500 ~ 1500 rpm
Power generation method	Water wheel
Water inlet method	Axial flow
Material	Pure copper
Weight	38kg

Features

Efficient energy production: 2kW hydro power generator achieves optimal power conversion with minimal water resources.
Advanced blade technology: Fewer blades design reduces vibration and enhances operational stability.
Adaptable installation: Miniature hydropower turbine suits various low-head water applications.
Sustainable operation: Environmentally friendly, produces clean energy.
Flexible application: Perfect portable water turbine for small dams, streams and remote power needs.

Structure Diagram

Installation Diagram

Application

Tips: Does a 2000W vertical hydroelectric turbine generator for home require a dam?

A domestic 2000 Watt hydro turbine generator typically doesn't require a large dam, but a low weir or small dam is generally required. Its primary function is to slightly raise the water level, creating the slight head required for power generation and providing a stable water diversion. Run-of-the-river design has a minimal environmental impact, as water flows back downstream. However, establishing such a facility may require consultation with and obtaining permission from local water authorities.
