1-2" Range Digital Micrometer, 0.0001 Inch Accuracy

0 reviews • Write a review

from

$153.96

Ex Tax: $153.96

Stock: In Stock
Model: RDDLZ-DM-1025
Weight: 1.00
SKU: RDDLZ-DM-1025

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

The electronic digital display micrometer uses a 3V large-capacity battery to ensure long-term measurement work, with a measuring range of 1~2 inches and an accuracy of 0.00005 inches. The digital outer diameter micrometer has mm/inch conversion/zero function for each position. Easy to use, suitable for novices and professionals alike.

Specification

Model	RDDLZ-JZ25-50
Digital Display Scale	Digital display + scale
Range	25~50mm (1~2 inch)
Resolution	0.001 mm (0.00005 inch)
Accuracy	±0.002mm (0.00005 inch)
Metric to English Conversion	Yes
Home Position Measurement	Yes
Data Hold	Yes
Power Supply	LR44 button cell
Out of Tolerance Alert	Yes
Scale Body Quality	High quality steel
Product Process	Surface spraying
Scale Process	Laser scale
Packaging	Drop-proof blow mold box

Set zero

Wipe the probe measuring.
Probe closure.
Lock the screw with the stopper.
Use a wrench to pull the fixing sleeve until the zero line is aligned.

Details

Tips: Precautions for using a digital screw gauge

A digital screw gauge is a precision gauge, in the use and preservation of the process to prevent the loss of accuracy such as drop collision, otherwise needs to re-check the calibration before use.
Use as much as possible to avoid exposure to dusty places, and avoid the sun's ultraviolet-level high-temperature radiation.
Do not put the digital micrometer on the magnetic object, the workpiece needs to demagnetize after measurement.
Gasoline or alcohol can be used to scrub the measuring surface.
Use temperature:0-40°C;Use humidity:≤80%
