Electronic Crane Scale for Marine, 1 ton/ 2.5 ton/ 5 ton, IP67

0 reviews • Write a review

from

$395.74

Ex Tax: $395.74

Stock: In Stock
Model: RDDLZ-CRS-103
Weight: 1.00
SKU: RDDLZ-CRS-103

Available Options

Capacity

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

The advanced wireless electronic weighing scale is suitable for a wide range of offshore operations, with a load capacity of up to 5 tons, zero drift and temperature changes have minimal impact on its accuracy, built-in high-strength aluminum alloy frame and IP67 protection level, durable and corrosion-resistant,. Equipped with advanced wireless transmission function, it can operate up to 200 meters and responds at 10kHz to ensure real-time data transmission without delay.

Specification

Model	RDDLZ-DST-BH-1T	RDDLZ-DST-BH-2.5T	RDDLZ-DST-BH-5T
Capacity	1000kg (1 ton)	2500kg (2.5 ton)	5000kg (5 ton)
Output Sensitivity	2.0 ± 0.05mV/V
Zero Output	±1% F.S.
Non-linearity	0.3% F.S.
Hysteresis	0.3% F.S.
Repeatability	0.1% F.S.
Creep	0.1% F.S. (30 minutes)
Temperature Sensitivity Drift	0.05% F.S./10°C
Zero Temperature Drift	0.05% F.S./10°C
Response Frequency	10kHz
Material	High strength aluminum alloy
Impedance	350Ω
Insulation Resistance	≥5000MΩ/100VDC
Operating Voltage	5-15V
Operating Temperature Range	-20°C~60°C
Safety Overload	1.5
Limit overload	3
Wireless Transmission Distance	200m (No Shade)
Endurance	6 hours

Feature

Peak Value Record: Peak and valley value historical data save 800 groups, power down not lost
Wireless Working Mode: Communication mode and distance, stable judgment, continuous working mode listening mode.
High-quality Steel Aluminum Alloy: Made of 7075 high-strength aviation aluminum materials, with a high degree of wear-resistant, corrosion-resistant, antioxidant and other excellent performance.
Waterproof Grade IP67: The protection grade of the electronic crane scale can do IP67, the use of the scene is mostly for outdoor or sea environment, the installation design of the full sealing considerations.

Dimensional Drawing (unit: mm)

Model	Rated Load	Dimension							Material	Net Weight
Model	Rated Load	øE	A	B	C	G	D	F	Material	Net Weight
RDDLZ-DST-BH-1T	1T	20	210	36	100	155	20	R15	High-strength aerospace aluminum	1KG
RDDLZ-DST-BH-2.5T	2.5T	20	210	36	100	155	20	R15	High-strength aerospace aluminum	1KG
RDDLZ-DST-BH-5T	5T	27	260	50	110	180	35	R20	High-strength aerospace aluminum	2KG

Details

Application

Tips: What marine environments are electronic hook scales suitable for?

Designed for marine environments, the electronic hook scale is able to cope with the high load weight measurement needs of ships, harbors and other offshore operations. It is made of waterproof and anti-corrosive materials to ensure stable operation in humid and high salinity environments. Whether it is lifting goods at sea, overhauling equipment on offshore platforms, or maintaining ships, the electronic hook scale can provide accurate weight data to help staff realize safe and efficient operations.

The electronic hook scale adopts high-precision sensors and advanced anti-interference technology to ensure that it can still provide accurate measurement results in offshore operations. The scale body is made of sturdy alloy material with high corrosion resistance and weather resistance, which can be used stably for a long time in extreme marine environments. In addition, it is equipped with a high-capacity battery that supports long-time operation and reduces the need for frequent recharging.
