Air Pressure Switch, 0.2 To 45 Bar

Air Pressure Switch, 0.2 To 45 Bar
Air Pressure Switch, 0.2 To 45 Bar
0 reviews • Write a review
from
$59.52
Ex Tax: $59.52
  • Stock: In Stock
  • Model: RDDLZ-PS-LF08
  • Weight: 1.00
  • SKU: RDDLZ-PS-LF08

Available Options

Add to Cart
Buy Now Question?
Add to Wish List Compare this Product

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Mechanical pressure switch with 5000 psi burst pressure, 6.35*0.8, 4.8*0.8, 18AWG wire leads electrical connections and 1/8 NPT, 1/4 NPT, G1/8, G1/4, 1/4 copper tube connection threads.

Specification

ModelRDDLZ-PS-LF08
MediaAir, water, motor oils, transmission oils, hydrocarbon media, refrigeration fluid
Pressure range/ tolerance/ proof pressurePressure rangeToleranceProof pressure
0.2~6 bar (low pressure)±0.5 bar15 bar
6~10 bar±0.7 bar35 bar
11~20bar±0.1 bar45 bar
21~30 bar±1.5 bar
31~45 bar±1.5 bar
Contact formsNO/ NC/ NO+NC
Base materialBrass/ plated steel
Burst pressure5000 psi
Connection thread1/8 NPT, 1/4 NPT, G1/8, G1/4, 1/4 copper tube
Electrical connections6.35*0.8, 4.8*0.8, 18AWG wire leads
Operating temperature rangeEnvironment temperature: low pressure: -30~65℃; High pressure: -35~120℃; Medium temperature: -50~120℃
Switch typeSPST (NC OR NO); SPDT
Electric rating120VAC 6FLA, 40.2LRA; 240VAC 4FLA, 26LRA; 120/ 240VAC 375VA; 36VDC 3A
Endurance100000
Pressure port10-30VDC
CertificateCE, RoHS, REACH
Warranty12 months

Dimensions (mm)

Tips: The features of Pressure Switch.
The main types of pressure switches include NO and NC. The main features are:
1. It adopts inch pipe thread quick joint or copper pipe welding type installation structure, which is flexible in installation and convenient to use, without special installation and fixation.
2. The plug-in wire type connection method can be selected by the user arbitrarily.
3. The sealed stainless steel sensor is safe and reliable.
4. The pressure range can be manufactured according to the pressure value arbitrarily selected by the user.
