9kW Portable Industrial Electric Fan Heater

0 reviews • Write a review

from

$368.24

Ex Tax: $368.24

Stock: In Stock
Model: RDDLZ-FH-09
Weight: 1.00
SKU: RDDLZ-FH-09

Available Options

Input Voltage (Three Phase)

Textarea

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Safe and reliable electrical fan heater is 9kW power, works at 50Hz three phase 380-400V AC power supply, air flow of 708m³/h and heating area of 180m³. IPX4 waterproof class, free-standing and portable, with affordable price, is perfect for heating up construction sites, factories, workshops, warehouses, garages, sheds, barns, and other industrial spaces.

Parameter List

Model		RDDLZ-EF09
Power		9kW
		30706 Btu/h
		7738.2 Kcal/h
Power Supply		Three phase 380-400V AC (50Hz) (Other voltages can be customized)
Heating Setting		52/4500/9000W
Air Output		410m³/h
Heating Area		180m³
IP Rating		IPX4
Installation		Free standing, Portable
Heating Element		Heating wire
Material		Cold-roll steel + stainless steel
Self Resetting Thermostat		80℃
Certification		CE, RoHS, EMC
Warranty		12 months
Fan Heater Applications		Living room, Garden, Construction site, Workshop or other industrial fields
Product Size		365315520mm
Net Weight		10.3kg

Fan Heater Details

Tips: After the fan heater is purchased, how can we do a good job in product acceptance?

At first, check whether the package is in good condition, check whether the accessories required are complete, check whether the parameters on the heater equipment nameplate are consistent with our requirements, and determine whether this is the model we ordered.

Secondly, check whether the fan heater equipment is damaged. If there is a serious collision during transportation, the equipment will be damaged. Therefore, the appearance of the equipment shall be checked in all aspects to see whether it is deformed, scratched or damaged. Check all parts of the heater to see whether the fasteners are loose or fall off and whether the parts are damaged. If there is any problem, repair or replace it before installation.

There is also to detect the insulation resistance between the heating equipment shell and the motor winding to ensure the safety of electricity. It is required that the insulation resistance between the shell of the culture heater and the motor winding shall be greater than 0.5 megohm, otherwise the motor winding shall be dried, and the temperature shall not exceed 120 ℃.
