Features

• With 1 hp (750W) powerful efficient motor, air blower can produce more airflow 33 m³/min.
• Convenient top-mounted handle design, easy to transport or carry.
• With reliable reinforced plastic housing and high quality metal fan impellers, low noise and high durability.
• Air intake/outlet is covered with a protective screen to effectively keep impurities out.
• Cheap yet reliable air blower pump is suitable for home and commercial bounce houses, bouncy castles, water slides, obstacle courses, jumpers and other inflatable games, and also great for advertising and promotional inflatables such as arches and mascots.

Specification

Note: * The inflatable air blower with 50Hz voltage is NOT suitable for use with 60Hz power supply.

Video - RDDLZ Inflatable Air Blower Overview

Applications

Tips: Proper Use of Air Blower

Proper use of air blower will make the blower perform better, and extend its service life. The following are some tips when using the air blower.

1. Except that the lubricating oil should be replaced after each repair, regular replacement of lubricating oil is required.

2. Check the bearing seat of type E drive regularly (quarterly), clean and add lubricating oil to prevent the bearing from burning out.

3. Check the sensitivity of the thermometer and the oil mark regularly, and control the oil level of the bearing box within the allowed range.

4. If it is found that the flow is too large and does not meet the use requirements, or a small flow is needed in a short time, the throttle device can be used for adjustment.

5. In the process of starting, stopping or running of the blower, if any abnormal phenomenon is found, it shall be checked immediately.

6. For minor faults found in the inspection, the cause shall be timely identified and the elimination or treatment shall be tried. If minor faults cannot be eliminated or major faults are found, the inspection shall be carried out immediately.
