6 Amp 4 Pole Miniature Circuit Breaker

0 reviews • Write a review

from

$86.79

Ex Tax: $86.79

Stock: In Stock
Model: RDDLZ-MCB-4P06
Weight: 1.00
SKU: RDDLZ-MCB-4P06

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

RDDLZ 4 pole C6 miniature circuit breaker (MCB) offers reliable protection for electrical systems, ensuring the safety and efficiency of the entire circuit. This 6 amp MCB with C trip characteristic ensures tripping in the event of an overload, preventing damage to the circuit and connected devices.

4 Pole MCB Breaker Information

Rated Current: 6 amp
Rated Voltage: 230/400V AC, 50Hz
Number of poles: 4 pole
6 kA rated short-circuit breaking capacity
Compliant with IEC standard
C curve trip characteristic
With overload protection and short circuit protection function

Technical Data

Model		RDDLZ-NB8-634PC06
Rated Current		6A
Rated Voltage		230/400V
Frequency		50Hz
Number of Poles		4P
Mechanical Life		20000 Times
Electrical Life		10000 Times
Rated Short-Circuit Breaking Capacity		6000A
Operating Short-Circuit Breaking Capacity		6000A
Rated Impulse Withstand Voltage (1.2/50)		6kV
Dielectric Test Voltage		2000V (50Hz, 1 min)
Heat & Humidity Resistance		28 Cycles
Vibration Resistance		No Obvious Vibration and Impact
Terminal Block	Terminal Block Type	Pillar Terminal Block
	Min. Terminal Size Acceptability	1mm²
	Max. Terminal Size Acceptability	25mm²
	Standard Connection Torque	2 N.m
	Max. Tolerable Torque	2.5 N.m
	Wire Insertion Depth	13mm
Reference Temperature		30℃
Operating Temperature		-35℃~+70℃
Storage Temperature		35℃~+85℃
Applicable Altitude		2000m
Tripping Mode		Thermal Magnetic Trip
Electromagnetic Tripping Type		Type C (5In-10In)
Shell Flame Retardant Grade		V0
Wire Entry Method		Both Upper and Lower
Installation Method		TH35-7.5 Standard Rail
Protection Level	Direct Installation	IP20B
	Installed in the Distribution Box	IP40B

4 Pole MCB Breaker Dimensions (Unit: mm)

Details

Tips: Miniature circuit breaker advantages

Miniature circuit breakers (MCBs) offer several advantages in electrical systems. Firstly, they provide effective protection against overloads and short circuits, safeguarding electrical circuits from damage due to excessive current. Mini MCBs are compact, making them ideal for use in confined spaces or residential and commercial applications where space is limited.

Micro circuit breakers are easy to install and reset, which reduces downtime compared to fuses that need to be replaced after being blown. Mini MCBs also offer higher reliability and faster response times, ensuring immediate disconnection when faults occur, and preventing potential fire hazards.

Moreover, they are cost-effective and offer long-lasting performance with minimal maintenance, making them a preferred choice for both professionals and DIY enthusiasts. Many MCBs also come with adjustable trip settings, providing flexibility to meet the needs of various electrical systems. This combination of reliability, safety, and convenience makes MCBs an essential component in modern electrical installations.
