Features

SSR 50Amps series single phase solid state relays are made of high quality and high structural strength, strong shock resistance, small driving current at the input end can easily interface with computer terminals and various digital programmed circuits. Beautiful and generous, excellent electrical conductivity, safe and reliable, long mechanical life. Able to control large current on and off with small control signals. They are commonly used in industrial automation, heating control, lighting control, motor control and other applications requiring electrical control.

• Exquisite workmanship
• Photoelectric isolation
• SSR output
• LED indicator for operation status
• Removable protective cover for safety
• Panel mount
• Zero-crossing switch type

Specification

Dimension

Wiring Diagram

Tips: Maintenance methods for solid state relays

When using solid state relays with small current specifications for printed circuit boards, the lead terminals are made of highly thermally conductive materials and should be soldered at a temperature of less than 250°C for less than 10S. If necessary, consider derating the load current to within 1/2 of the rated value if the surrounding temperature is a factor.

Solid state relays should be installed away from electromagnetic interference, radio frequency interference sources, to prevent the relay false operation out of control. Solid state relay open circuit and the load side of the voltage, the output will have a certain leakage current, in the use or design should be noted. When the solid state relay fails to replace, try to use the prototype or technical parameters of the exact same product, in order to match the original application line, to ensure the reliable operation of the system.
