12V/24V DC Cooling Fan, 60mm X 60mm X 15mm

0 reviews • Write a review

from

$26.89

Ex Tax: $26.89

Stock: In Stock
Model: RDDLZ-CF-DC6015
Weight: 1.00
SKU: RDDLZ-CF-DC6015

Available Options

Short Description

Rated Voltage

Model

Interface

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

12 volt / 24 volt dc cooling fan dimensions of 60mm x 60mm x 15mm, high efficiency, superior performance, are widely used in computers, communications products, optical products, and cars.

Specifications:

Model

RDDLZ-DC6015SLL

RDDLZ-DC6015BLL

RDDLZ-DC6015SLM

RDDLZ-DC6015BLM

RDDLZ-DC6015SLH

RDDLZ-DC6015BLH

Rated Voltage

12V

24V

12V

24V

12V

24V

12V

24V

12V

24V

12V

24V

Bearing Type

Oily

Ball

Oily

Ball

Oily

Ball

Rated Current

0.09A

0.07A

0.09A

0.07A

0.1A

0.08A

0.1A

0.08A

0.12A

0.1A

0.12A

0.1A

Input Power

1.08W

1.68W

1.08W

1.68W

1.2W

1.92W

1.2W

1.92W

1.44W

2.4W

1.44W

2.4W

Fan Speed

3000±10%RPM

3500±10%RPM

4000±10%RPM

Air Flow

12.4CFM

14.4CFM

16.5CFM

Static Pressure

1.9mm-H2O

2.2mm-H2O

2.5mm-H3O

Noise

25dB-A

29dB-A

33dB-A

Dimension

60mm x 60mm x 15mm

Material

Plastic

Certificate

CE, UL

Fire Rating

UL94V-0

Operating Temperature

-10 ℃ ~ 70 ℃

Operating Humidity

35% ~ 85RH

Storage Temperature

-40 ℃ ~ 70 ℃

Storage Humidity

35% ~ 85RH

Dimensions and Curves (unit: mm)
DC Cooling Fan Interface

Tips: What is the air volume and air pressure of the cooling fan?
The cooling fan air volume refers to the total volume of air sent or drawn by the fan per minute. The unit of air volume often used in fan products is CFM, which is Cubic Feet per Minute.
When the materials are the same and the heat dissipation principle is the same, the air volume is the most important index to measure the heat dissipation capacity. Simply put, a fan with a larger air volume has a higher heat dissipation capacity. This is because the heat capacity of air is constant, and the larger the air volume, that is, the more air can take away more heat per unit time. The air pressure of a cooling fan is also called static pressure, which refers to the difference in air pressure between the fan's air inlet and air outlet. Usually, the unit is millimeter of water column height (mmH2O) or inch of water column height (inchH2O).
