Customized step up or step down toroidal transformers with 600VA capacity, 1-phase, a single 240V/50-60Hz primary winding, 12V/ 24V/ 2x50V AC secondary winding for selecting, manufactured, and tested in compliance with CE, RoHS, ISO standards.

Advantages of RDDLZ Toroidal Transformer

1. High Efficiency: Winding matches the core perfectly, which makes the transformer more efficient.
2. Long Service Life: With high-quality materials and manufacturing technology, the transformer can be used for 30 years.
3. Less Noise: The core is seamlessly rolled and the winding is set evenly over it, which makes the transformer quiet when it is working.
4. Less Radiation: Toroidal structure and winding technology reduce electromagnetic radiation.
5. Low Temperature Rise: Even if it is overloaded at 120%, the temperature rise will be less than 70℃.

600VA Toroidal Transformer Specifications

Toroidal Transformer Accessories

Toroidal Transformer Mounting Methods

Toroidal Transformer Internal Structure

Tips: How to distinguish the input and output of a toroidal transformer without lable?

The toroidal transformer is composed of input and output leads, so it is very important to correctly distinguish the input end from output end of toroidal transformer. If you fail to connect the input and output ends of toroidal transformer correctly, the transformer will be burnt down. What's more, the machine will be burnt down on a serious level. Therefore, it is necessary to correctly distinguish the input end from output end of transformer in use.

Generally, toroidal transformer manufacturers will attach labels on transformers in the production, so as to facilitate users for identification. So how to distinguish the input end from output ends of toroidal transformers without label? Here are two simple methods:

1. Instrument measurement

the multiple-use meter is used to measure the copper resistance value (single winding for secondary line) of transformers. There are two situations:

• When measuring step-down transformer, the end with large winding resistance value is the input end, otherwise, it is the output end.
• When measuring step-up transformer, the end with small winding resistance value is the input end, otherwise, it is the output end.

2. Appearance discrimination

The diameter of enamel-insulated wires (single winding for secondary line) is observed. Also, there are two situations:

1. For a step-down transformer, the end with more winding coils and finer enamel-insulated wires is the input end, otherwise, it is the output end.
2. For a step-up transformer, the end with less winding coils and thicker enamel-insulated wires is the input end, otherwise, it is the output end.
