50 Amp 1 Pole Miniature Circuit Breaker

0 reviews • Write a review

from

$58.49

Ex Tax: $58.49

Stock: In Stock
Model: RDDLZ-MCB-1P50
Weight: 1.00
SKU: RDDLZ-MCB-1P50

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

50 amp single pole miniature circuit breaker (MCB) is a protective device used in electrical systems to protect circuits from damage caused by overcurrent or short circuits. This mini circuit breaker has protection functions of short circuit, overload, and circuit break, and can be mounted on a 35mm DIN rail.

Single Pole MCB Breaker Features

Rapid arc extinguishing system: This single pole mini circuit breaker eliminates line danger, can sense even small currents, and provides sensitive protection.
Thermosetting shell: 1 pole MCB breaker uses thermosetting plastic, which solidifies or has insoluble characteristics under heat or other conditions.
Sealed terminal: 50 amp miniature circuit breaker has a built-in sealed terminal, which is rust-proof and convenient, and meets certification standards.
Ergonomic handle: The handle is comfortable to operate, has high segmentation capacity, and is sensitive to action.

Technical Data

Model	RDDLZ-BY6-63-1P-50A
Number of Poles	1P
Rated Frequency	50-60Hz
Frame Grade Current	63A
Rated Current(In)	50A
Rated Insulation Voltage	400V
Rated Impulse Withstand Voltage (Uimp)	4000KV
Rated Short-circuit Capacity(Inc)	3000-6000KA
Producible Leakage Protection Type	AC type
Electrical Characteristics	Short Circuit Protection, Overload Protection, Power Failure Protection
Electrical Life	10000
Mechanical Life	10000
Protection Level	IP20
Comply with the Standard	GB/T10963.1-2020 IEC60898-1

Single Pole MCB Breaker Dimensions (Unit: mm)

Single Pole MCB Breaker Wiring

How to Choose a Miniature Circuit Breaker for Home?

Rated Current	Copper Core Wire	Load Power	Applications
1~5A	＜1mm	≤1100W	Low-power Equipment
6A	≥1mm	≤1320W	Lighting
10A	≥1.5mm	≤2200W	Lighting
16A	≥2.5mm	≤3520W	Lighting, Sockets, 1~1.5 hp Air Conditioner
20A	≥2.5mm	≤4400W	Lighting, Sockets, 1~1.5 hp Air Conditioner
25A	≥4mm	≤5500W	Lighting, Sockets, 1~2.5 hp Air Conditioner
32A	≥6mm	≤7040W	Sockets, 3 hp Air Conditioner, 6 kW Water Heater
40A	≥10mm	≤8800W	8 kW Instant Water Heater, Main Power Switch
50A	≥10mm	≤11000W	Main Power Switch
63A	≥16mm	≤13200W	Main Power Switch

Tips: 50 amp 1 pole miniature circuit breaker applications

A 50 amp 1 pole miniature circuit breaker (MCB) is commonly used in residential, commercial, and light industrial applications to protect electrical circuits from overloads and short circuits. In residential settings, it’s typically used for high-power appliances like electric water heaters, ovens, and air conditioning units. In commercial buildings, it can protect lighting circuits, small machinery, and HVAC systems. Light industrial applications include safeguarding equipment like small motors and specialized tools.

The single pole design means the mini MCB protects one live wire, making it suitable for 120V circuits in North America or single-phase circuits in other regions. Its compact size allows easy installation in standard electrical panels, saving space while ensuring reliable protection. Additionally, the quick trip mechanism prevents damage to connected devices and reduces fire risks. Always ensure compatibility with the circuit’s voltage and load requirements, and consult local electrical codes or a qualified electrician before installation.
