3 Phase 2 Hp (1.5kW) Regenerative Blower, 380V, 124cfm
from
$731.73
Ex Tax: $731.73
- Stock: In Stock
- Model: RDDLZ-RB-380-1500
- Weight: 1.00
- SKU: RDDLZ-RB-380-1500
Available Options
Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.
RDDLZ provides cheap price high pressure 1500W regenerative blower online. It can meet your air volume demand of 210 m³/ h and the noise is as low as 64 decibels.
Specification
Model | RDDLZ-2PB510H26 |
Phase | 3 |
Frequency | 50 |
Power | 2 hp (1.5 kW) |
Voltage (AC) | △220-240V / Y345-415V |
Current | 7.5△ A / 4.3Y A |
Max airflow | 210 m³/ h (124 cfm) |
Rated vacuum pressure | -200 mbar |
Rated compress pressure | 190 mbar |
Noise | 64 dB (A) |
Weight | 26 kg |
Dimention (Unit: mm)
A | B | C | D | E | F | G | H | J | K | L | M | N | O | ΦP | Q | ΦR | S | U | V (1~) | V' (1~) | V1 (3~) | V1' (3~) | YXZ | X-HOLES | ΦX | W |
334 | 337 | 120 | 260 | 295 | 346 | 191 | 175 | 128 | 115 | 155 | 96 | 87 | 48 | 55 | 72 | 14 | 4 | M8X17 | / | / | M25X1.5 | M16X1.5 | M8X20 | 0°/ 120°/ 240° | 200 | 29 |
Details
Tips: Features of 3 phase 2 hp (1.6 kW) high pressure regenerative blower
- High power and low energy consumption. The 2 hp (1.6 kW) high pressure regenerative blower can still operate safely even when the application scene changes.
- The equipment is simple and can be installed in the horizontal or vertical direction.
- High reliability. The 3-phase 2 hp (1.6 kW) high pressure vortex blower has no moving parts except the impeller, almost free of repairs.
- Low tremor. The mechanical precision of the high pressure regenerative blower is high, and the rotating parts have passed precise balance planning, inspection, and correction, so the vibration rate is very low.
- Low noise. Directly driven by a low-noise motor, with a built-in silencer to reduce operating noise.
- The structure is stable. The 1.6 kW 3 phase high pressure regenerative blower is made of aluminum alloy and milled alloy, which is different from ordinary aluminum or iron shell high pressure fans, and is more stable and durable.
- There are many types of RDDLZ high pressure blowers. In addition to the three phase 2 hp vortex blowers with high pressure and large air volume, you can also buy 3 phase 1.1 hp regenerative blowers, 3 phase 0.7 hp regenerative blowers, etc., which can be used flexibly.
- No oil and no pollution.
