100μF 35V Aluminum Electrolytic Capacitor

0 reviews • Write a review

from

$1.14

Ex Tax: $1.14

Stock: In Stock
Model: RDDLZ-EC-KF101M035F
Weight: 1.00
SKU: RDDLZ-EC-KF101M035F

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

High voltage capacitor with direct plug installation type, the size is 6.3*11 mm, 3000 hours endurance, operating tempertaure -40~105℃. Power capacitor providing good electrical performance, wide application range and high reliability.

Features

Endurance: 105℃- 2000 hours up to 5000 hours
Low impedance and high ripple current
High reliability
Wide voltage range

Specification

Model		RDDLZ-EC-KF101M035F
Series		Low impedance 105°C type
Capacity		100 ㎌
Rated voltage		35V
Installation Type		Direct plug
Size		6.3*11 mm
lead spacing		2.5 mm
Operating temperature		-40~105℃
Cap. tolerance (∆C)		±20% (120Hz 20℃)
Dissipation factor (tanδ)		10%
Low temperature characteristic at 120Hz (Z ratio max.)		3 (Z-25℃/ Z+20℃)
Leakage current (L_leak)		≤0.01CRV_Ror 3 ㎂ * after 2 minutes
Enduarance (105℃)	Test	3000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value
Shelf life (105℃)	Test	1000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value

Dimension (mm)

Model	Dimension (mm)
KF101M035F	∅D	8
	F	3.5
	∅d	0.5
	a	1.5

Tips: How to Choose Aluminum Electrolytic Capacitor?

The voltage that the capacitor actually has to withstand in the circuit cannot exceed its withstand voltage value. In the filter circuit, the withstand voltage value of the capacitor should not be less than 1.42 times the RMS value of the AC. When using electrolytic capacitors, be careful not to reverse the positive and negative poles.

Different circuits should use different types of capacitors. Mica, high-frequency ceramic capacitors can be used for the vibration circuit, paper, polyester, mica, electrolytic, ceramic capacitors can be used for DC blocking, electrolytic capacitors can be used for filtering, and polyester, paper, ceramic, electrolytic capacitors can be used for bypass.

Before installing the capacitor into the circuit, check whether it has short circuit, open circuit and leakage, and check its capacitance value. When installing, make it easy to see symbols such as the type, capacity, and withstand voltage of the capacitor for verification.
