10μF 25V Aluminum Electrolytic Capacitor

0 reviews • Write a review

from

$1.06

Ex Tax: $1.06

Stock: In Stock
Model: RDDLZ-EC-KF100M
Weight: 1.00
SKU: RDDLZ-EC-KF100M

Available Options

Short Description

Qty

Add to Cart

Buy Now Question?

Add to Wish List Compare this Product

Shipping & Returns

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Additional Product Info

Create unlimited custom product blocks and display them in accordions or tabs or open blocks. Each block can be assigned to all products at once or specific products according to advanced criteria.

Cheap price aluminum capacitor with size 5*11 mm, operating tempertaure -40~105℃, 1000 hours shelf life. The power capacitor has advantages of high reliability, small size and long service life.

Features

Endurance: 105℃- 2000 hours up to 5000 hours
Low impedance and high ripple current
High reliability
Wide voltage range

Specification

Model		RDDLZ-EC-KF100M
Series		Low impedance 105°C type
Capacity		10 ㎌
Rated voltage		25V
Installation Type		Direct plug
Size		5*11 mm
Operating temperature		-40~105℃
Cap. tolerance (∆C)		±20% (120Hz 20℃)
Dissipation factor (tanδ)		12%
Low temperature characteristic at 120Hz (Z ratio max.)		3 (Z-25℃/ Z+20℃)
Leakage current (L_leak)		≤0.01CRV_Ror 3 ㎂ * after 2 minutes
Enduarance (105℃)	Test	2000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value
Shelf life (105℃)	Test	1000h
	∆C	≤20% of initial measured value
	tanδ	≤200% of specified measured value
	L_leak	≤ the specified measured value

Dimension (mm)

Model	Dimension (mm)
RDDLZ-EC-KF100M	∅D	5
	F	2
	∅d	0.5
	a	1.5

Tips: How to Install Aluminum Electrolytic Capacitor?

Used capacitors are not reusable，except in the case that the capacitors are detached from a device for periodic inspection to measure theirelectrical characteristics.
lf the capacitors have self-charged, discharge the capacitors through aresistor of approximately 1kQ before use.
lf capacitors are stored at a temperature of 35°C or more and more than 75% RH,the leakage current may increase. lIn this case，they can be re-formed by applying the rated voltage through a resistor of approximately 1kQ.
